Klixon thermal switch + circuit breaker 1Amp.

Single pole, miniaturised, aircraft style thermal circuit breaker with tease-free, trip-free, snap action mechanism and push/pull on/off manual actuation.
Single hole threadneck mounting.
The 7277-2 series circuit breaker is physically and electrically identical to the 7274-2 series circuit breaker, with the exception that the 7277 series has wider calibration limits.
Featuring an ergonomically styled two colour actuator with white indicator band clearly showing the tripped/OFF position.
Pull for trip/off position (white indicator band appears), push again for reset.


Specifications:
Electrical connection: 2x screw
Amp rating: 1A
Max voltage: 30V DC / 120V AC
Weight: 28gram

Dimensions:
L= 50mm
W= 14mm
H= 19mm
